erformance Features
- Rugged Reliable 86cc Engine: Honda’s proven 86cc SOHC four-stroke engine offers smooth, useable power delivery and legendary reliability. Convenient, push-button electric starter ensures hassle-free starting in all conditions.
Engine
- Engine Type: 86cc air-cooled SOHC single-cylinder four-stroke
- Bore And Stroke: 47.0mm x 49.5mm
- Induction: 15mm piston-valve carburetor
- Ignition: CDI
- Starter: Electric
Drive Train
- Clutch: Automatic
- Transmission: Four-speed
- Driveline: O-ring-sealed chain
Chassis Suspension Brakes
- Front Suspension: Independent suspension; 2.6-inches of travel
- Rear Suspension: Swingarm with single shock; 2.6-inches of travel
- Front Brakes: Dual sealed drum
- Rear Brake: Sealed drum
- Front Tires: 20 x 7-8
- Rear Tires: 19 x 8-8
Dimensions
- Length: 58.6 inches
- Width: 35.2 inches
- Height: 36.5 inches
- Wheelbase: 38.7 inches
- Seat Height: 26.0 inches
- Ground Clearance: 3.9 inches
- Turning Radius: 8.3 feet
- Curb Weight: 262 pounds (Includes all standard equipment, required fluids and a full tank of fuel—ready to ride)
- Fuel Capacity: 1.7 gallons, including 0.3-gallon reserve
Other
- Available Colors: White, Red
- Model ID: TRX90X
- Note: Recommended for riders 10 years of age and older. Honda recommends that all ATV riders take a training course and read their owner’s manual thoroughly. TRX90X riders younger than 16 years of age must be supervised by an adult.
